Vonnic VVR9928D 28 CH Full D1 HD Standalone DVR System
UPC: 814927012141
| Model | VVR9928D |
| Channel / Compression | 28 CH BNC H.264 |
| Video Format | NTSC / PAL |
| Video Input | BNC X 28 |
| Video Output Channel | 1-BNC, 1-VGA, 1-HDMI, 1-YPbPr, 1-Spot Output |
| Loop Output |
Not Support |
| HDMI Output | 1920x1080i50/ 1920 x 1080i60 |
| YPbPr Output | 1920x1080i50/ 1920 x 1080i60 |
| VGA Output | 1280 x 1024 |
| Live Output Mode | All channels are double field |
| D1 Record Frame Rate | 700fps(PAL)/840fps(NTSC) |
| CIF Record Frame Rate | Not Support |
| D1 Playback Frame Rate | 100fps(PAL)/120fps(NTSC) |
| CIF Playback Frame Rate | Not Support |
| Network Resolution /fps | CIF > 10fps for each channel |
| Audio In |
RCA X 16 |
| Audio Out | RCA X 1 |
| Alarm Input | 16 |
| Alarm Output | Relay output, Normal open(NO), Normal close(NC), COM |
| Alarm Mode | Sensor input alarm, disk full alarm, motion detection alarm, viseo loss alarm |
| Record Mode | Time / sensor / motion /detection |
| Network Protocol | TCP/IP, Static IP, DHCP, DDNS |
| Network Remote | Remote Monitoring, recording via IE browser. CMS software |
| USB Port | Two USB 2.0 Host |
| Hard Drive Storage | Maximum 7 x 2.0 TB SATA Hard Drive |
| DVD-RW | Optional |
| PTZ | RS-485 |
| Mobile Surveillance | iPhone / Android/ Blackberry / Windows Mobile / Windows Symbian |
| Power Supply | 220V / 110V |
| Power (without hard drive) | <50W |
| Package Dimension (WxDxH) | 17x16.3x3.8in (43.5x41.5x10cm) |
| Package Weight | 17lbs (8.0 kg) |
